DeepCool CG530 Bulk Reverse Fan Silent Operation Fluid Dynamic Bearing
DeepCool CG530 Bulk Reverse Fan Silent Operation Fluid Dynamic Bearing
- Fast UK Shipping
- 14 Days Return
- Secure Payment
Couldn't load pickup availability
Share
Description
Description
Equipped with ARGB lighting, the fan offers vibrant illumination to complement your system's aesthetics. The hydro bearing technology ensures quiet operation and longevity, while the anti-vibration rubber pads minimize noise and vibration.
With PWM control, the fan speed can be adjusted based on system requirements, providing a balance between cooling performance and noise levels.
Key Features:
Efficient Cooling: Delivers high airflow and static pressure for effective cooling.
ARGB Lighting: Enhances the visual appeal of your PC with vibrant illumination.
Quiet Operation: Hydro bearing and anti-vibration pads ensure minimal noise.
PWM Control: Allows dynamic adjustment of fan speed based on system needs.
Specifications:
General:
Model Number:
R-EDF120-BKAPR17-G-1
Color:
Black
Quantity:
1 Fan
Fan Dimensions:
Size:
120 × 120 × 25 mm
Weight:
Approximately 150 g
Performance:
Speed:
500–1800 RPM ±10%
Airflow:
Up to 61.91 CFM
Static Pressure:
Up to 1.83 mmH2O
Noise Level:
=28 dB(A)
Electrical:
Rated Voltage:
12 VDC (Fan), 5 VDC (LED)
Rated Current:
0.13 A (Fan), 0.21 A (LED)
Power Consumption:
1.56 W (Fan), 1.05 W (LED)
Connectors:
Fan Connector:
4-pin PWM
LED Connector:
3-pin ARGB
Lighting:
Type:
RGB
Control:
Compatible with standard RGB controllers
Bearing Type:
Hydro Bearing
Materials:
Frame:
PBT (Polybutylene Terephthalate)
Blades:
Polycarbonate
Noise Dampening:
Rubber Pads:
Anti-vibration pads at each corner
Package Contents:
1 × 120mm RGB PWM Case Fan
Mounting Screws
User Manual
Warranty:
2 Years
Specifications
Specifications
- Product Type: Case Fan
- Fan Size: 120mm
- Max Fan Speed: 1800RPM
- Fan Shroud Colour: Black
- LED Colour: Addressable RGB
- Connections: 4-Pin Fan & 3-Pin ARGB
